Mechanical pedestrian push buttons

  • All-metal construction
  • Precision snap-action dry contact switch
  • ADA compliant
  • IP rating: 62
  • Operating force: < 3 lbf
  • Life expectancy: 10 million operations
  • Voltage: up to 250 V (AC/DC)
  • Max current: 15 A
  • Operating temperature: -15 °C to +80 °C
  • Available in round (3″), rectangular (2.8″ x 4.5″), and large rectangular (5″ x 9″)
  • Colors: black, yellow, green, natural (powder coat finish)
  • ISO 9001:2015 certified
  • 5-year warranty
  • Urban or rural signalized intersections
  • School zones, residential areas, or commercial districts
  • High-use or vandal-prone public environments
  • Safe and inclusive pedestrian crossings
  • Urban infrastructure projects with actuated traffic
  • Improve pedestrian crossing safety
  • Vandal-resistant
  • Adapted for users with visual or mobility impairments
  • Compatible with actuated systems
  • Synchronizable with visual and audible signals

Traditional, robust, and long-lasting buttons.

Constructed entirely from metal, these push buttons offer superior vandal resistance and extended service life. They use a precision snap-action dry contact switch and comply with ADA accessibility standards. Their robust and ergonomic design is ideal for urban crossings with high usage and challenging environments. Available in multiple sizes and finishes for flexible installation.

  • All-metal construction
  • Precision snap-action dry contact switch
  • ADA compliant
  • IP rating: 62
  • Operating force: < 3 lbf
  • Life expectancy: 10 million operations
  • Voltage: up to 250 V (AC/DC)
  • Max current: 15 A
  • Operating temperature: -15 °C to +80 °C
  • Available in round (3″), rectangular (2.8″ x 4.5″), and large rectangular (5″ x 9″)
  • Colors: black, yellow, green, natural (powder coat finish)
  • ISO 9001:2015 certified
  • 5-year warranty
  • Urban or rural signalized intersections
  • School zones, residential areas, or commercial districts
  • High-use or vandal-prone public environments
  • Safe and inclusive pedestrian crossings
  • Urban infrastructure projects with actuated traffic
  • Improve pedestrian crossing safety
  • Vandal-resistant
  • Adapted for users with visual or mobility impairments
  • Compatible with actuated systems
  • Synchronizable with visual and audible signals
